MODEL TYPES

What is included in each Model Type option?

Initial PDF, Initial BIM Model or Initial CAD Model content:

• 3D BIM Model of the house contains all main elements modeled - levels, walls, doors, windows, floors, furniture, etc. (for the Initial BIM Model only).

• Cover sheet with camera view of the house and a sheet list

• Floor plans (including basement where applicable), scale 1/4"=1'-0": dimensioned plans showing all main elements of the house - walls, floors, stair (where applicable), windows, doors, furniture, plumbing fixtures, etc.

• Roof plan, scale 1/4"=1'-0": dimensioned plan showing all roof slopes, gutters, eaves, skylights, exterior wall outline below, etc.

• Four exterior elevations, scale 1/4"=1'-0": showing all levels, eave lengths, roof slopes, doors and windows, etc.

• At least two Building Sections, scale 1/4"=1'-0": showing all levels, walls, floors, stair, roof slopes, eave lengths, doors and windows, etc.

Planning PDF, Planning BIM Model or Planning CAD Model content:

What is NOT included:

• Architectural or Engineering Stamps
• General notes, City Notes
• Wall, Floor, Ceiling and Roof Assemblies
• Site Plan
• Mechanical and Plumbing
• Energy Calculations
• Structural Calculations and Plans
• Finish Floor Plans and Schedules
• Door and window schedules and types
• Light fixture, Accessories, Equipment and Plumbing Schedules
• Casework and millwork schedules and types
• Exterior, Interior, Window and Door Details

Design PDF, Design BIM Model or Design CAD Model content:

What is NOT included:

• Site Plan - has to be handled locally
• Architectural or Engineering Stamps - have to be handled locally
• Mechanical and Plumbing Drawings - have to be handled by your subcontractors
• Energy calculations - have to be handled locally if required
• Structural Calculations - have to be handled locally
• Framing Plans and details - have to be handled locally
• Wall, Floor, Ceiling and Roof assemblies
• Finish Floor Plans and Schedules
• City Notes
• Details

Construction PDF, Construction BIM Model or Construction CAD Model content:

How will I receive my ordered products?
Electronic delivery: URL for downloading the files will be provided after completing the purchase and approving the payment. Normally approving the payment takes 1-3 minutes. Order the product, complete the payment, wait few minutes and then go to My Account > Orders or click here to view your order. Verify that your order status is completed and then click "VIEW" to open the order details and download the purchased product. As well you will receive the download URL on your email address when your payment is approved.
